FluidLogic VMR System: Hydration for
Champions

Trusted by top teams in NASCAR, IndyCar, IMSA, WEC, and Off-Road Racing, the FluidLogic VMR System is the ultimate hands-free hydration solution. Designed for peak performance, it delivers water at preprogrammed intervals via a steering wheel-mounted push-to-drink microbutton, keeping drivers focused on winning.

Featuring our MagLock magnetic connections, check valves for a drip-free experience, and a fully programmable pump controlled via the iOS app, the system ensures effortless hydration. Water flows from a quick-connect, vacuum-insulated bottle through insulated fluid lines to the Aqua Com, a low-profile silicone sleeve that fits over most microphones—keeping every sip ice-cold and helmet clutter-free.

2025 Upgrades

✔ Upgraded Pump – Automatic priming, even when dry
✔ Low Power Draw – Just 0.6 amps for maximum efficiency
✔ Extreme Reliability – Built for the most demanding conditions
✔ Redesigned Aqua Com – Easier helmet installation, compatible with most microphones
✔ Steering Wheel Integration – Use your existing steering wheel drink button. Our drink signal supports both switch-to-ground and switch-to-positive configurations on the same wire

PART NUMBER: VMR32-MLD-1000 & VMR64-MLD-1000

Features

Optimal Fluid Absorption
Heightened Mental Acuity
Faster Recovery Time

What’s Included

Hydration System Components:
✔ (1) 32oz or 64oz bottle with hose clamps
✔ (1) Pod with mount and hose clamps
✔ (1) 12V cable
✔ (1) Pod-to-dash cable
✔ (1) Steering wheel microbutton
✔ (1) Fluidline with heat shrink (Bottle to Pod and Pod to Hub)

Fluid Delivery System: MagLock Duo

MagLock Duo Kit Includes:
✔ (1) Hub (Splices between air hose to run waterline to hose-side MagLock)
✔ (1) 6mm waterline (Hub to helmet-side magnetic connection)
✔ (1) Coaxial MagLock (Helmet and hose-side magnetic connections)
✔ (1) 4mm waterline (Helmet-side magnetic connection to Aqua Com)
✔ (2) Aqua Com microphone sleeves (1 Baja – Large, 1 Pro – Small)
✔ (1) Roof Dock (Stores hose-side magnetic connection when not in use)

Specs & Material

  • Pod Dimension: 180.6 mm x 70 mm x 68.4 mm
  • Pod Weight: 320g
  • Supply Voltage: +6VDC to +18VDC
  • Supply Current:
    - Idle: 0.04A
    - Pumping: <1A at 12VDC (depending on fluid path components)
  • System Flow Rate: 750ml/min
  • BLE 5.2 connectivity to Fluidlogic accessories
  • Environmental: IP67
  • System Storage Temp: 3 – 85C
  • Usage Temp: 3 – 50 C
  • Water Temperature: 3 – 50C
  • Altitude: Less than 2000m
  • iOS 13 and up App
  • Certifications for both USA/EU
    - USA – Prop 65

Customizable Hydration Control via iOS App:

✔ Adjust the volume of dispensed water
✔ Adjust the pressure of dispensed water
✔ Adjust the hydration reminder interval
✔ Adjust the LED idle and reminder brightness

Product Manuals

POD Assembly Instructions
Duo Assembly Instructions

View full details

VMR DUO FAQs

Does the FluidLogic VMR System with MagLock Duo include the water bottle and air hose?

If you purchase the VMR System with MagLock Duo bundle, you can choose which bottle option you want to add. Our bottles come in 32oz and 64oz capacities. However, air hose is not included, and must be purchased seperately.

Can I purchase different lengths of air hose?

Yes, air hose is available in 4ft, 6ft, 8ft, and 10ft lengths.

My pod (pump) wont prime, how do I prime the system?

Remove the gray 90 degree elbow from the hub (coupler between your air hose) and press the microbutton until water comes out. You can also try sucking on the elbow fitting until you start pulling water through, then reconnect the elbow to the hub and press the button until water starts squirting from the coaxial MagLock.
